SH Power possesses a well-established R&D and engineering team capable of tailoring exclusive solutions for various project requirements. From system design to on-site application, we provide comprehensive technical support, helping customers achieve safe, intelligent, and highly efficient power distribution systems.
The GGF low-voltage reactive power compensation device effectively improves the power factor, reduces line losses, and enhances transformer load capacity, delivering significant energy savings. Equipped with specific reactors, it suppresses harmonic amplification and absorbs harmonic currents, ensuring total harmonic distortion (THD) meets national standards. Highly versatile, it is compatible with various switchgear such as MNS, GCS, and GGD, and supports multiple compensation configurations including Wye, Delta, and combined connections. It utilizes maintenance-free capacitors with a service life of over 100,000 hours and ensures accurate and safe control.
| Rated voltage | Below AC 400 V | |||||
| Rated frequency | 50Hz | |||||
| Rated compensation capacity | 60-420Kvar | |||||
| Operating voltage range | 0.8-1.1Un | |||||
| Capacitor connection method | △ or Y | |||||
| Voltage measurement error | ±0.5% | |||||
| Switching mode | Automatic cyclic switching,Individual-phase switching | |||||
| Switching delay | 0–999 adjustable | |||||
Our switchgear, including C-GIS and ring main units, features a compact and modular design, saving valuable installation space and allowing for flexible expansion and easy on-site assembly.
With all high-voltage components sealed in a stainless-steel gas tank, our equipment is protected from environmental factors. It features reliable mechanical and electrical interlocks to ensure the safety of operators.
Committed to sustainability, we offer eco-friendly switchgear that uses dry air as the insulating medium, completely eliminating SF₆ gas and minimizing environmental impact.
The fully sealed and insulated design ensures our switchgear is virtually maintenance-free throughout its service life, significantly reducing operational costs and downtime.
Our products can be integrated with intelligent solutions, supporting remote monitoring, control, and automated distribution systems, which is crucial for building modern smart grids.
Ideal for secondary distribution substations, industrial parks, commercial buildings, and residential communities, providing reliable power control and protection.
Perfectly suited for renewable energy applications such as wind farms and solar power plants, where compact and reliable switchgear is essential for power collection and grid connection.
Deployed in critical infrastructure like subways, railways, airports, and tunnels, where space is limited and high reliability is non-negotiable.
Used in demanding environments such as mining, petrochemical plants, and data centers that require robust, safe, and uninterrupted power management.
